Whiteline Rear Sway Bar Links for Mitsubishi Evo X – KLC174

Description

Whiteline Rear Sway Bar Links for Mitsubishi Evo X – KLC174

Firstly, BUY Whiteline Evo X Rear Sway Bar Links KLC174. Upgrade the rear suspension response of your Mitsubishi Lancer Evolution X with the Whiteline Rear Sway Bar Links KLC174. Designed specifically for the Evo X platform, these adjustable heavy-duty rear sway bar links provide a stronger and more precise connection between the rear anti-roll bar and suspension. The KLC174 uses adjustable ball-and-ball links with heavy-duty steel ball joints, allowing the link length to be adjusted to help eliminate unwanted sway bar preload during installation.

The Whiteline Rear Sway Bar Links are particularly useful when upgrading the Evo X suspension with an aftermarket rear sway bar, changing ride height, or replacing worn factory end links. The adjustable design provides up to 25 mm of centre-to-centre adjustment, allowing the sway bar to be positioned correctly for the vehicle’s suspension setup.

Firstly, the heavy-duty ball-joint construction helps reduce the flex and compliance associated with standard suspension links. This creates a more direct connection between the rear sway bar and suspension, helping the anti-roll bar respond more consistently to suspension movement.

Secondly, the adjustable length allows the installer to set the link correctly after changing ride height or installing a different rear sway bar. This is particularly important on modified Evo X vehicles where suspension geometry differs from the factory configuration.

Thirdly, the KLC174 uses ball joints that can rotate through different angular positions, helping accommodate suspension movement and making installation easier. Whiteline specifies a 10 mm ball stud, a 130–155 mm adjustable length, and a horizontal heavy-duty ball-joint configuration.

Whiteline Rear Sway Bar Links Features

The Whiteline Rear Sway Bar Links KLC174 offer several features designed for performance-oriented Evo X suspension systems:

• Whiteline part number: KLC174
• Rear sway bar/end link application
• Adjustable extra-heavy-duty design
• Adjustable length: 130–155 mm
• Up to 25 mm centre-to-centre adjustment
• 10 mm ball studs
• Horizontal ball-and-ball configuration
• Heavy-duty steel ball-joint ends
• Adjustable ball joints that rotate through different angular positions
• High-quality alloy construction
• Anodized alloy finish for corrosion and wear resistance
• Designed to help eliminate sway bar preload
• Helps reduce unwanted flex and compliance
• Designed for improved sway bar effectiveness
• Supplied as a 2-link kit
• Installation guide included

Designed for the Mitsubishi Evo X Suspension

The KLC174 is designed for the Mitsubishi Lancer Evolution X, making it a suitable suspension upgrade for Evo X GSR, MR and other applicable CZ4A configurations. Whiteline’s current catalog lists KLC174 as a rear anti-roll bar link for the Evo 10, with two links supplied per vehicle.

The product is also listed for 2008–2015 Mitsubishi Evolution X applications by multiple performance-parts suppliers.

As with any suspension component, confirm the exact vehicle year and configuration before ordering, particularly if the vehicle has aftermarket suspension, modified ride height, or other chassis changes.

Adjustable Length for Better Sway Bar Setup

One of the main advantages of the KLC174 is its adjustable length. The links can be adjusted from approximately 130 mm to 155 mm, providing up to 25 mm of centre-to-centre adjustment.

This adjustment can be valuable when installing a larger aftermarket rear sway bar or lowering an Evo X with coilovers. Changes in ride height can affect the position of the suspension and sway bar, potentially introducing preload when the vehicle is sitting at normal ride height.

The adjustable KLC174 allows the installer to set the link length appropriately rather than being limited to the fixed length of an original-style end link.

Heavy-Duty Ball Joint Construction

The KLC174 uses heavy-duty steel ball-joint ends that can rotate through different angular positions. This design helps the link accommodate suspension articulation while maintaining a direct connection between the sway bar and suspension.

Whiteline combines these ball joints with an alloy adjustable body. The alloy components are anodized to provide a protective surface against corrosion and wear while maintaining a lightweight construction.

For an Evo X used for spirited street driving, autocross, track days or other performance applications, properly configured sway bar links can complement upgraded anti-roll bars and other suspension components.

Benefits for a Modified Evo X

The KLC174 is especially relevant for Mitsubishi Evolution X owners who have modified their suspension beyond the original factory configuration.

If your Evo X has been lowered with coilovers, fitted with an aftermarket rear sway bar, or equipped with upgraded suspension bushings, adjustable rear sway bar links can help the suspension components work together more effectively.

The goal is not simply to install a stronger link. Correct link length and suspension positioning are also important. The KLC174 provides the adjustment necessary to help minimize unwanted sway bar preload and maintain the intended operation of the rear anti-roll bar.

For a complete suspension build, the links can be paired with performance coilovers, sway bars, control-arm bushings, trailing-arm bushings and other Mitsubishi Evo parts.

Installation

Professional installation is recommended, particularly if the vehicle has aftermarket suspension components.

The KLC174 should be installed with the vehicle at the appropriate ride height, and the adjustable link length should be set according to the vehicle’s suspension configuration. Correct installation can help minimize unwanted sway bar preload.

Whiteline lists an installation time of approximately 60 minutes, although actual installation time can vary depending on vehicle condition and the existing suspension setup.

After installation, inspect all mounting hardware and suspension components before driving the vehicle. If the vehicle’s ride height or suspension geometry has been significantly changed, a professional alignment is recommended.

Buy Whiteline KLC174 Rear Sway Bar Links Online

If you are looking to buy Whiteline rear sway bar links online for your Mitsubishi Evo X, the KLC174 provides an adjustable solution specifically developed for the rear anti-roll bar system.

When you shop for Mitsubishi Evo parts, selecting the correct suspension components is important. The KLC174 is particularly suited to Evo X owners who want adjustable rear sway bar links rather than a basic fixed-length replacement.

The two-link configuration makes the KLC174 a complete rear sway bar link kit for the applicable vehicle.

Whether you are building a performance street Evo X, a track-focused CZ4A, or simply replacing worn suspension links, the KLC174 can be integrated into a wider suspension upgrade package.

BUY Whiteline Evo X Rear Sway Bar Links KLC174, Adjustable 130–155mm heavy-duty links with 10mm ball joints for improved rear sway bar setup.

Vehicle Fitment

• Mitsubishi Lancer Evolution X
• 2008–2015 Mitsubishi Evolution X
• Applicable CZ4A Evo X configurations
• Rear suspension / rear anti-roll bar application

Always verify the vehicle year and suspension configuration before ordering.

Package Includes

• 2 × Whiteline KLC174 Rear Sway Bar Links
• Installation guide

Frequently Asked Questions

What is Whiteline KLC174?

Whiteline KLC174 is an adjustable heavy-duty rear sway bar link kit designed for the Mitsubishi Lancer Evolution X. It uses adjustable ball-and-ball links with 10 mm ball studs.

How much adjustment does KLC174 provide?

The KLC174 has an adjustable length of approximately 130–155 mm, providing up to 25 mm of centre-to-centre adjustment.

Does KLC174 fit the Evo X?

Yes. Whiteline lists KLC174 for the Mitsubishi Lancer Evolution X, and current fitment information covers 2008–2015 Evo X applications.

Does KLC174 come as a pair?

Yes. The kit contains 2 rear sway bar links, sufficient for one vehicle.

Why use adjustable sway bar links?

Adjustable links allow the installer to alter the link length and help minimize sway bar preload, which can be particularly useful after changing ride height or installing an aftermarket sway bar.

Are the KLC174 links suitable for aftermarket sway bars?

Yes. The adjustable design is intended to work with modified suspension and sway bar configurations and can help set the rear sway bar without unwanted preload.

Are these front or rear sway bar links?

KLC174 is specifically a rear sway bar link application. Whiteline lists the fitting position as the rear axle.

Why Buy from EvoMotorParts.com?

• Quality Mitsubishi Evolution performance parts
• Genuine OEM and premium aftermarket components
• Performance suspension parts for Evo 7, Evo 8, Evo 9 and Evo X
• Competitive pricing
• Worldwide shipping
• Dedicated customer support for Mitsubishi Evolution enthusiasts

Conclusion

The Whiteline Rear Sway Bar Links KLC174 are an adjustable, heavy-duty suspension upgrade designed specifically for the Mitsubishi Lancer Evolution X. With 130–155 mm adjustment, heavy-duty steel ball joints, an anodized alloy body and a two-link configuration, the KLC174 provides the adjustment and durability required for modified Evo X suspension systems.

For Evo X owners upgrading sway bars, lowering their vehicle, replacing worn end links or refining their suspension setup, the KLC174 provides an adjustable connection between the rear anti-roll bar and suspension.

Shop and order Whiteline KLC174 rear sway bar links from Evomotorparts.com for your Mitsubishi Evolution X build, with worldwide shipping available.
